Rotary Table Accumulators

Mini-Mover Rotary Table Accumulators (RTAs) were originally designed for the metalworking marketplace to promote unattended machine operation and separation of sensitive parts after machining. These types of units are also called “accumulation tables” or “lazy susans” in the industry

Our RTA units are well suited for various applications in metalworking, assembly and packaging, such as cycle tolerance inspection, surge table on production lines and staging for manual or pick & place case packing.

Now Available: Our RTA units are also available with 12″ diameter (60-012) and 16″ diameter (60-016) tabletops.

MMini-Mover RTA Model 60-048 Inch Rotary Table Accumulator

48-inch Rotary Table Accumulator (RTA)

Product Specifications

  • Weight: 145 pounds
  • Table Diameter: 48 inches
  • Load Capacity: 100 pounds
  • Roller Base: 19.5″ square with heavy-duty locking casters
  • Part Stop Cushion: Height and angle adjustable
  • Diverter Fence: Height and angle adjustable

Table Height (adjustable):

  • Option A: 20″ to 28″
  • Option B: 28″ to 36″

Table Rotation Options

  • Variable Speed: 1 through 3 rpm
Mini-Mover RTA Model 60-032 Inch Rotary Table Accumulator

32-inch Rotary Table Accumulator (RTA)

Product Specifications

  • Weight: 120 pounds
  • Table Diameter: 32 inches
  • Load Capacity: 100 pounds
  • Roller Base: 19.5″ square with heavy-duty locking casters
  • Part Stop Cushion: Height and angle adjustable
  • Diverter Fence: Height and angle adjustable

Table Height (adjustable):

  • Option A: 20″ to 28″
  • Option B: 28″ to 36″
  • Option C: 36″ to 42″

Table Rotation Options

  • Fixed Speed: 1 rpm or 3 rpm
  • Variable Speed: 1 through 3 rpm
Mini-Mover RTA Model 60-024 Inch Rotary Table Accumulator

24-inch Rotary Table Accumulator (RTA)

Product Specifications

  • Weight: 95 pounds
  • Table Diameter: 24 inches
  • Load Capacity: 60 pounds
  • Table Height (adjustable): 16″ to 34″
  • Roller Base: 19.5″ square with heavy-duty locking casters
  • Part Stop Cushion: Height and angle adjustable
  • Diverter Fence: Height and angle adjustable

Table Rotation Options

  • Fixed Speed: 1 rpm or 3 rpm
  • Variable Speed: 1 through 3 rpm
Mini-Mover RTA Models 60-012 and 60-16 Inch Rotary Table Accumulators

12- and 16-inch Rotary Table Accumulator (RTA)

Product Specifications

  • Weight: 85 pounds
  • Table Diameter: 12 and 16 inches
  • Load Capacity: 50 pounds
  • Table Height (adjustable): 16 to 34 in.
  • Roller Base: 19.5 in. square with heavy-duty locking casters
  • Part Stop Cushion: Height and angle adjustable
  • Diverter Fence: Height and angle adjustable

Table Rotation Options

  • Fixed Speed: 1 rpm or 3 rpm
  • Variable Speed: 1 through 3 rpm
